Printing Method
Printing Technology 12-Color inkjet printer, non-firing nozzle detection and compensation
Maximum Resolution 2400 x 1200 dpi
Minimum Ink Droplet Size 4.0 pl
Ink Type LUCIA EX pigment-based ink
Ink Palette Cyan, Photo Cyan, Magenta, Photo Magenta, Yellow, Black, Matte Black, Red, Green, Blue, Gray, Photo Gray
Ink Cartridge Configuration 12 individual cartridges
Number of Nozzles Per Color: 2560 nozzles
Total: 30,720
Nozzle Pitch 1200 dpi
Printer Language GARO
Paper Handling
Paper-Feed Method Roll: front output
Sheet: top-loading/front-loading, front output
Cutter Automatic
Maximum Printable Area 24.0″ x 59.0′ (60.96 cm x 18.0 m)
Borderless Photo Sizes Width: 10.0″ (25.4 cm), 14.0″ (35.56 cm), 16.0″ (40.64 cm), 17.0″ (43.18 cm), 24.0″ (60.96 cm), B4, A3+, A2, A2+, B2, A1
Paper Sizes Standard: B2, JIS B3, D, C, Ledger, Super B, Letter, Legal, ARCH D, ARCH C, ARCH B, ARCH A, DIN C2, DIN C3, DIN C4, 20.0 x 24.0″ (50.8 x 60.96 cm), 18.0 x 22.0″ 45.72 x 55.88 cm), 14.0 x 17.0″ (35.56 x 43.18 cm), 12.0 x 16.0″ (30.48 x 40.64 cm), 10.0 x 12.0″ (25.4 x 30.48 cm), 10.0 x 15.0″ (25.4 x 38.1 cm), 16.0 x 20.0″ (40.64 x 50.8 cm), 20.0 x 30.0″ (50.8 x 76.2 cm), 13.0 x 22.0″ 33.02 x 55.88 cm), 11.81 x 35.43″ (30.00 x 90.00 cm)
Custom – Top Feed: 8.0 x 10.98 to 24.02 x 62.99″ (20.32 x 27.9 to 61.0 x 160.0 cm)
Custom – Front Feed: 9.84 x 13.78 to 24.02 x 35.98″ (25.0 x 35.0 to 61.0 x 91.4 cm)
Paper Types Glossy, Proofing, Coated, Matte, Fine Art
Media Thickness Sheet (Top-Loading): 3.2 to 31.4 mil (0.07 to 0.8 mm)
Sheet (Front-Loading): 19.6 to 59.0 mil (0.5 to 1.5 mm)
Roll: 3.2 to 31.4 mil (0.07 to 0.8 mm)
Maximum Roll Print Length 59.0′ (18.0 m)
Maximum Media Roll Diameter 5.9″ (150 mm)
Core Size 2.0 or 3.0″ (5.08 or 7.62 cm)
Connectivity
Computer Interface USB: High-Speed USB 2.0
Network: 10/100/1000 Base-T/TX Ethernet
OS Compatibility Windows: Windows 7 (32/64-bit), Vista (32/64-bit), XP
Mac: OS X
Internal Memory 384 MB
Physical
Control Panel LCD
LEDs: Data, Message, Cut Sheet, Roll Media
Buttons: Power, Stop, Navigate, 4 arrow buttons, OK, Back, Menu, Cut, Feed, Load
Power Requirements 100 to 240 V AC, 50 to 60 Hz
Power Consumption Maximum: ≤ 100 W
Standby: ≤ 6 W
Power Off: ≤ 0.5 W
Acoustic Noise Noise Level: ≤ 47 dB(A)
Acoustic Power: ≤ 6.4 B(A)
Certifications International Energy Star, Eco Mark, Law On Promoting Green Purchasing, GPN, RoHS, Eco Declaration, WEEE, US Presidential Directives, ErP Directive
Temperature / Humidity Operating Temperature: 59 to 86 °F (15 to 30 °C)
Operating Humidity: 10 to 80%
Dimensions (WxDxH) 48.3 x 34.3 x 39.4″ (122.68 x 87.12 x 100.08 cm)
Weight 154 lb (69.85) including stand
Packaging Info
Package Weight 155.0 lb
Box Dimensions (LxWxH) 53.0 x 37.5 x 36.0″
