Printing Method
Printing Technology 10-channel, drop-on-demand, inkjet PrecisionCore TFP Print Head
Maximum Resolution 2880 x 1440 dpi
Print Speed 16 x 20″ / 40.6 x 50.8 cm Print: 2:02 to 6:58 (production is 4:16)
20 x 30″ / 50.8 x 76.2 cm Print: 3:40 to 12:25 (production is 7:36)
40 x 60″ / 101.6 x 152.4 cm Print: 11:15 to 40:05 (production is 24:20)
Minimum Ink Droplet Size Enhanced Variable Droplet Technology as small as 3.5 pl
Ink Type UltraChrome HDX pigment inks
Ink Cartridge Configuration 11 individual cartridges
Ink Color C, LC, VM, VLM, Y, LK, V, O, G, PK/MK
Compatible Ink Cartridges T834100 UltraChrome HD Photo Black Ink Cartridge (150 ml)
T834200 UltraChrome HD Cyan Ink Cartridge (150 ml)
T834300 UltraChrome HD Vivid Magenta Ink Cartridge (150 ml)
T834400 UltraChrome HD Yellow Ink Cartridge (150 ml)
T834500 UltraChrome HD Light Cyan Ink Cartridge (150 ml)
T834600 UltraChrome HD Vivid Light Magenta Ink Cartridge (150 ml)
T834700 UltraChrome HD Light Black Ink Cartridge (150 ml)
T834800 UltraChrome HD Matte Black Ink Cartridge (150 ml)
T834A00 UltraChrome HDX Orange Ink Cartridge (150 ml)
T834B00 UltraChrome HDX Green Ink Cartridge (150 ml)
T834D00 UltraChrome HDX Violet Ink Cartridge (150 ml)
T824100 UltraChrome HD Photo Black Ink Cartridge (350 ml)
T824200 UltraChrome HD Cyan Ink Cartridge (350 ml)
T824300 UltraChrome HD Vivid Magenta Ink Cartridge (350 ml)
T824400 UltraChrome HD Yellow Ink Cartridge (350 ml)
T824500 UltraChrome HD Light Cyan Ink Cartridge (350 ml)
T824600 UltraChrome HD Vivid Light Magenta Ink Cartridge (350 ml)
T824700 UltraChrome HD Light Black Ink Cartridge (350 ml)
T824800 UltraChrome HD Matte Black Ink Cartridge (350 ml)
T824A00 UltraChrome HDX Orange Ink Cartridge (350 ml)
T824B00 UltraChrome HDX Green Ink Cartridge (350 ml)
T824D00 UltraChrome HDX Violet Ink Cartridge (350 ml)
T804100 UltraChrome HD Photo Black Ink Cartridge (700 ml)
T804200 UltraChrome HD Cyan Ink Cartridge (700 ml)
T804300 UltraChrome HD Vivid Magenta Ink Cartridge (700 ml)
T804400 UltraChrome HD Yellow Ink Cartridge (700 ml)
T804500 UltraChrome HD Light Cyan Ink Cartridge (700 ml)
T804600 UltraChrome HD Vivid Light Magenta Ink Cartridge (700 ml)
T804700 UltraChrome HD Light Black Ink Cartridge (700 ml)
T804800 UltraChrome HD Matte Black Ink Cartridge (700 ml)
T804A00 UltraChrome HDX Orange Ink Cartridge (700 ml)
T804B00 UltraChrome HDX Green Ink Cartridge (700 ml)
T804D00 UltraChrome HDX Violet Ink Cartridge (700 ml)
Number of Nozzles 360 nozzles x 10
Automatic Black Ink Switching Matte to Photo Black: 2 min 55 sec, 7.2 ml
Photo to Matte Black: 2 min 7 sec, 1.12 ml
Media Handling
Paper Handling Top-loading feeder
Built-in rotary cutter
Media bin
Paper Sizes Minimum Cut-Sheet Size: 8.5 x 11″ / 21.6 x 27.9 cm
Maximum Paper Width: 44″ / 111.8 cm
Maximum Roll Size: Up to 44 x 529″ / 111.8 x 1343.7 cm
Borderless Printing Width 10″ / 25.4 cm, 11.8″ / 30 cm , 13″ / 33 cm, 16″ / 40.6 cm, 17″ / 43.2 cm, 20.3″ / 51.6 cm, 23″ / 58.4 cm, 24″ / 61 cm, 33″ / 83.8 cm, 36″ / 91.4 cm, 44″ / 111.8 cm
Line Accuracy ±0.2% or specified length
Media Thickness 31.5-59.1 mil / 0.8-1.5 mm
Print Archival Life Color: Up to 200 years
Black & White: Up to 400 years
Connectivity
Interfaces USB 2.0
1000Base-T Ethernet
OS Compatibility Windows 10, 8.1, 7 (32/64-bit)
Mac OS X 10.7-10.10
Printer Language Epson ESC/P raster photographic drivers standard
Physical
Control Panel Front panel with 2.7″ / 6.9 cm color LCD screen
Power Requirements 100-240 VAC, 50-60 Hz,
Power Consumption Printing: 75 W
Ready: 19 W
Sleep: 2 W
Power Off:
Certifications ENERGY STAR compliant
Acoustic Noise 47 dB(A)
Operation Conditions Temperature: 50 to 95°F / 10 to 35°C
Humidity: 20 to 80%, non-condensing
Recommended Temperature: 65 to 75°F / 18 to 24°C
Recommended Humidity: 40 to 60%, non-condensing
Storage Conditions Temperature: -4 to 104°F / -20 to 40°C
Humidity: 5 to 85%, non-condensing
Dimensions 74 x 48 x 26″ / 188 x 122 x 66 cm
Weight 298 lb / 135 kg
