Frameset
Frame Alpha Platinum Aluminum, internal storage, tapered head tube, Knock Block 2.0, Control Freak internal routing, downtube guard, shuttle guard, threaded BB, ISCG 05, 34.9mm seat tube, magnesium rocker link, Mino Link, ABP, Boost148, 160mm travel
Fork RockShox Lyrik Select+, DebonAir spring, Charger 2.1 RC damper, tapered steerer, 42mm offset, Boost110, 15mm Maxle Stealth, 170mm travel
Shock NEW RockShox Super Deluxe Ultimate, DebonAir spring, Thru Shaft 3-position damper, 230x62.5mm
Max compatible fork travel 180mm (596mm axle-to-crown)
Wheels
Wheel front Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle
Wheel rear Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Rapid Drive 54, SRAM XD driver, Boost148, 12mm thru axle
Hub front Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15mm thru axle
Skewer rear Bontrager Switch thru axle, removable lever
*Tire Size: S , M , ML , L , XL
Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29x2.40''
Size: S , M , ML , L , XL
Bontrager XR5 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29x2.60''
*Tire part Size: S , M , ML , L , XL
Bontrager TLR sealant, 6oz
Size: S , M , ML , L , XL
Bontrager TLR valve, 50mm
Rim strip Bontrager TLR
Max tire size Frame: 29x2.50" Fork: See manufacturer
Drivetrain
Shifter SRAM GX Eagle, 12 speed
Rear derailleur SRAM GX Eagle
*Crank Size: S
SRAM X1 Eagle, DUB, 30T steel ring, Boost (55mm chainline), 170mm length
Size: M , ML , L , XL
SRAM X1 Eagle, DUB, 30T steel ring, Boost (55mm chainline), 175mm length
Bottom bracket SRAM DUB MTB Wide, 73mm, BSA threaded
Cassette SRAM Eagle XG-1275, 10-52, 12 speed
Chain SRAM GX Eagle, 12 speed
Max chainring size Max: 34T, Min 28T
Components
Saddle Bontrager Arvada, hollow chromoly rails, 138mm width
*Seatpost Size: S
TranzX JD-YSP39, 100mm travel, internal routing, 34.9mm
Size: M , ML
TranzX JD-YSP39, 150mm travel, internal routing, 34.9mm
Size: L , XL
TranzX JD-YSP39, 170mm travel, internal routing, 34.9mm
Handlebar Bontrager Line, alloy, 35mm, 27.5mm rise, 820mm width
Grips Bontrager XR Trail Pro, alloy lock-on
Stem Bontrager Line, 35mm, Knock Block, 0 degree, 40mm length
Headset Knock Block 2.0 Integrated, 72-degree radius (includes infinite-radius chip), sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom
Brake SRAM Code R 4-piston hydraulic disc
*Brake rotor Size: S , M , ML , L , XL
SRAM CenterLine, 6-bolt, round edge, 180mm
Size: S , M , ML , L , XL
SRAM CenterLine, 6-bolt, round edge, 200mm
Accessories
Bag Bontrager BITS Internal Frame Storage Bag
Weight
Weight M - 15.04 kg / 33.15 lbs (with TLR sealant, no tubes)
Weight limit This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
